Year | 2024 |
Frame | ALUXX SL-grade Aluminium, Advanced Forged Composite linkage, 140mm Maestro Suspension System, 'Boost' 148x12 UDH rear axle, Giant EnergyPak Plus Range Extender Compatible |
Fork | Fox 36 Float Rhythm E-Tuned, 29er, 150mm travel, 44mm offset, Grip Damper, Sweep adjust, Boost 110x15QR |
Rear Shock | Fox Float Performance, EVOL Large Volume sleeve, 3-position Lever, 185x52.5mm Trunnion mount, custom tuned, recommended sag: 30% |
Motor | Giant SyncDrive Pro2 85Nm, PedalPlus 6-Sensor technology |
Control System | Giant RideControl Ergo3, grip integrated remote. Giant RideControl App enabled ANT+ wireless display signal with e-bike profile |
Battery | Giant EnergyPak 800Wh, 22700 Lithium cell technology, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production Giant EnergyPak Plus 250 range extender compatible |
Display | Giant RideControl GO, frame integrated LED console Optional wireless ANT+ display |
Shifters | Shimano SLX 1x12 |
Rear Mech | Shimano SLX, 12-speed, Shadow+ |
Front Mech | MRP HD2 co-moulded chain guide |
Bottom Bracket | n/a |
Chainset | Praxis Wave tm 36T Cold Forged 4130 premium steel chain ring 104BCD Praxis e-crank arm set (S:160, M/L:165, XL:170) Q-factor=168mm, Chainline: 55mm, Max Chainring: 38T |
Cassette | Shimano CS-M6100-12, 10-51T, 12-speed |
Chain | KMC e.12 Turbo, EcoProteq, e-bike optimised |
Brakes | Shimano Deore, BR-M6120, 4-piston, hydraulic disc, 203mm |
Pedals | Flatpedal |
Wheelset | Rims: Giant AM 29", Tubeless ready, 30mm inner width. Hubs: Shimano MT410 Boost, Center-Lock, [F] 110x15 [R] 148x12mm Micro-Spline Drive Body Thru-axle |
Tyres | Maxxis Minion DHF 29x2.6" foldable, Tubeless, EXO+, 3C MaxxTerra [F]Maxxis Dissector 29x2.6" Foldable, Tubeless, EXO+, 3C MaxxTerra [R] |
Handlebar | Giant Contact 35 Trail, 35x780mm |
Stem | Giant Contact SL 35 |
Grips | Giant Tactal Pro-E, tapered design, 135mm Ø28~30mm (S/M) 142mm Ø29~32mm (L/XL) |
Seatpost | Giant Contact Switch, dropper, 30,9mm (S:125mm, M:150mm, L/XL:170mm) |
Saddle | Giant Romero |
Headset | |
Extras | Giant EnergyPak 6A smart charger, 60% in 3:00h. Tubeless kit (liquid, valves, levers, manual, tool) |
