Year | 2024 |
Colour | Gloss Digital Blurple |
Frame | Advanced-grade composite front and rear triangles, 140mm Maestro Suspension, flip chip – Maestro 3, flip chip – headset, integrated down tube storage |
Fork | Fox 36 Float Rhythm, 150mm, Grip damper, Boost 15x110 Kabolt X, tapered, 44mm offset |
Rear Shock | Fox Float Performance, 185x52.5, custom tuned for Liv |
Shifters | Shimano SLX M7100, 1x12 |
Rear Mech | Shimano SLX M7100, Shadow + |
Front Mech | N/A |
Bottom Bracket | Shimano, press fit |
Chainset | Shimano MT512-1, 30t, 55mm chainline m |
Cassette | Shimano SLX M7100, 10x51 |
Chain | KMC X12 |
Brakes | Shimano Deore BR-M6120, hydraulic, Shimano RT-66 [F] 203mm, [R] 180mm rotors |
Pedals | Not Supplied |
Wheelset | Giant TRX 27.5"/29" hookless carbon wheelsystem 30mm rim inner width 40mm outer width 72t, POE, 28 SP spokes, DBL technology XD driver body 27.5"R/29"F for frame sizes XS/S 29"F&R for frame sizes for M/L |
Tyres | Size XS, S, M and L, [F]: Maxxis Minion DHF 29x2.5WT, 3C Max Terra, EXO, TR, tubeless Size XS&S, [R]: Maxxis Dissector 27.5x2.4WT, 3C Max Terra, EXO, TR, tubeless Size M&L, [R]: Maxxis Dissector 29x2.4WT, 3C Max Terra, EXO, TR, tubeless |
Handlebar | Giant Contact TR35, 20mm rise |
Stem | Giant Contact SL, 35mm |
Grips | Liv Tactal Pro Single Lock-on |
Seatpost | Giant Contact Switch, adjustable dropper, remote. XS&S: 140-170mm travel / 30.9 x 470mm, M&L: 170-200mm travel / 30.9 x 530mm |
Saddle | Liv Sylvia |
Headset | |
Extras | 3M tailgate protector, factory tubeless set up, integrated down tube storage bag, max tire size 2.5", max chainring size 34t |
