Large Trek Marlin+ 8 Fury Red

Trek Marlin+ 8 Fury Red

Cross Country Electric Bicycle
Trek Marlin+ 8 Fury Red
Click to Enlarge Image

Web Price: £2,650.00

53 Podium Points™ with this bike - Up to 20% of this bike's value in Free Accessories

Select a size:
Stock StatusDelivery
XS
Call for Alternatives
S
ETA - October
M
ETA - November
L
ETA - October
XL
ETA - October

Collect In Store - To collect or view a bicycle in our North Hampshire store please arrange prior to travelling. You can arrange this by calling us on 0118 9821021 or by selecting the Click & Collect method at checkout.


Description

Product video available. Please accept marketing cookies to watch this embedded video.

The Marlin+ is an affordable e-mountain bike that combines the best features of Trek and Bosch to enhance off-road rides. With the reliable Bosch Active Line Plus mid-drive motor and Trek's renowned bike design, this e-MTB offers seamless pedal-assist for enjoyable extended rides on trails and in urban environments. The Marlin+ doesn’t skimp on performance and reliability, instead blending them together to deliver a premium e-MTB experience at a price that’s accessible to a wide range of riders.

The new Bosch Active Line Plus mid-drive motor delivers the same refined performance and reliability you’ve come to expect from Bosch. It puts out a mid-power 50 Nm of torque which draws less power from the battery and doesn’t overwhelm the rider. It’s also much quieter than high-powered e-bikes.

Bosch CompactTube 400 - A 400-watt-hour battery is fixed inside the downtube. The new battery is more energy dense, which means more power in a lighter, smaller package.

Bosch Purion 200 - The display and remote are now combined into one simple, beautiful piece. The full colour display provides all the information riders need in a compact package.

AUTO mode - In the spirit of keeping things simple and fun, an 'AUTO' mode provides adaptive motor support so riders can hit the trail without worrying about which mode they’re in. If you run into a hilly section or headwind, the motor will increase support accordingly so you can pay attention to the ride instead of fiddling with your bike.

Marlin+ is equipped with fast rolling 29’’ wheels with grippy 2.6’’ tyres for tons of traction and all-sort of off-road versatility. Extra-small and Small frame sizes are equipped with more proportional 27.5’’ wheels.

A 120 mm* travel front suspension fork flattens out roots, rocks and bumps in the trail. A dropper seat post makes it easy to get the saddle out of the way. Front and rear thru-axles add stiffness for precise handling, while a Universal Derailleur Hanger (UDH) makes service easy and future upgrades possible. (*100mm on XS)

The Marlin+ is the go-to for riders looking to dip their toes into the electric mountain bike world. Its trail-savvy frame gives you confident control, and a Bosch Active Line Plus motor offers enough power to take the burn out of long climbs.

Please note: This model features tubeless ready wheels and tyres which offer a superior ride and less rolling resistance than traditional innertubes. This system requires tyre sealant to function correctly and this will be fitted in our workshop prior to despatch. The nature of this sealant means that the tyre may not be fully sealed until it has been ridden a short distance and therefore the bicycle may arrive with reduced pressure in the tyres. Please check the bicycle's tyres are inflated to the recommended pressure before cycling.

Please note: This model offers electric assistance up to speeds of 25kph (15.6mph).

Important Note: This bicycle requires a suspension pump to set and tune its suspension correctly. This is not included as standard. A suspension pump can be selected for no cost using Podium Points™.


Specification

YearGeneration 1
ColourFury Red/Lithium Fade
FrameSize: XS - Alpha Gold Aluminium, curved top tube, tapered head tube, internal routing, rack, mudguard and kickstand mount, UDH, Boost148, 12 mm thru axle
Size: M , L , S , XL - Alpha Gold Aluminium, tapered head tube, internal routing, rack, mudguard and kickstand mount, UDH, Boost148, 12 mm thru axle
ForkSize: XS - RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 46 mm offset, Boost110, 15 mm Maxle Stealth, 100 mm travel
Size: S - RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 46 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel
Size: M , L , XL - RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel
Rear ShockN/A
MotorBosch Active Line Plus, 50 Nm
BatteryBosch CompactTube 400 Wh
DisplayBosch Purion 200
ChargerBosch standard 2A, 230V, smart system
ShiftersShimano Deore M6100, 12-speed
Rear MechShimano Deore M6100, long cage
Front MechN/A
Bottom Bracket
ChainsetFSA CK-220, 165 mm length
CassetteShimano Deore M6100, 10-51, 12-speed
ChainShimano Deore M6100, 12-speed
BrakesShimano 4-piston hydraulic disc, MT4100 lever, MT420 calliper
PedalsVP-536 nylon platform
RimsBontrager Line TLR 30, Tubeless-Ready, 28-hole, Presta valve
HubsShimano TC500 alloy, CentreLock, thru axle
Spokes14 g stainless steel, black
TyresSize: XS , S - Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 27.5x2.60"
Size: M , L , XL - Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.60"
HandlebarSize: XS , S - Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width
Size: M , L , XL - Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width
StemSize: XS , S - Bontrager Comp, 31.8 mm, 7-degree, 35 mm length
Size: M , L - Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Size: XL - Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length
GripsTrek Line Comp, nylon lock-on
SeatpostSize: XS , S - TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length
Size: M , L , XL - TranzX JD-YSP18, 150 mm travel, internal routing, 31.6 mm, 470 mm length
SaddleBontrager Verse P3, steel rails
HeadsetSemi-integrated, sealed cartridge bearing, alloy cups, 1-1/8" top, 1.5" bottom
Extras

We are an authorised Trek dealer and supply this Trek Marlin+ 8 Fury Red with a lifetime manufacturer's warranty (frame). Find More Detailed Warranty Information Here


Sizing

SizeRider Height (ft)Rider Height (m)
XS4'9"-5'1"1.45-1.55
S5'1"-5'5"1.55-1.65
M5'5"-5'9"1.65-1.76
ML5'8"-5'11"1.73-1.80
L5'10"-6'2"1.77-1.88
XL6'2"-6'5"1.88-1.95
Sizing information is provided as a general guide only. This is based on the average rider riding the bicycle in the style for which it is intended. This takes no account of a rider's personal proportions, physique, flexibility and biomechanics. If your height places you on, or near, a bicycle size step then we recommend you consider both sizes. All bicycles offer a range of handlebar and saddle adjustment which will enable you to fine tune your riding position once the correct size has been established. If you are unsure on sizing, we strongly recommend you visit our store so we can assist you.

Geometry

Geometry key
Frame SizeXSSMLXL
Seat Tube C-T mm A340370420450500
Horiz. Top Tube mm B551584620652682
Seat Angle C73.8°73.8°73.8°73.8°73.8°
Head Angle D66.5°66.5°66.5°66.5°66.5°
Head Tube mm E90100105115135
Chainstay mm F470470485485485
BB Offset mm G4545606060
BB Height mm H313313318318318
Standover mm I366398443454458
Wheelbase mm J11291166121812511284
Reach mm K390415440470495
Stack mm L563590626635653
Fork Rake mm M4242464646
Fork Trail mm N110110114114114
Stem Length mm3535505060
Bar Width mm720720750750750
Crank length mm165165165165165
Wheel size27.5"27.5"29"29"29"
