Year | Generation 1 |
Colour | Purple Flip/Black Fade |
Frame | Size: XS - Alpha Gold Aluminium, curved top tube, tapered head tube, internal routing, rack, mudguard and kickstand mount, UDH, Boost148, 12 mm thru axle Size: M , L , S , XL - Alpha Gold Aluminium, tapered head tube, internal routing, rack, mudguard and kickstand mount, UDH, Boost148, 12 mm thru axle |
Fork | Size: XS - RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 46 mm offset, Boost110, 15 mm Maxle Stealth, 100 mm travel Size: S - RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 46 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel Size: M , L , XL - RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel |
Rear Shock | N/A |
Motor | Bosch Active Line Plus, 50 Nm |
Battery | Bosch CompactTube 400 Wh |
Display | Bosch Purion 200 |
Charger | Bosch standard 2A, 230V, smart system |
Shifters | Shimano Deore M6100, 12-speed |
Rear Mech | Shimano Deore M6100, long cage |
Front Mech | N/A |
Bottom Bracket | |
Chainset | FSA CK-220, 165 mm length |
Cassette | Shimano Deore M6100, 10-51, 12-speed |
Chain | Shimano Deore M6100, 12-speed |
Brakes | Shimano 4-piston hydraulic disc, MT4100 lever, MT420 calliper |
Pedals | VP-536 nylon platform |
Rims | Bontrager Line TLR 30, Tubeless-Ready, 28-hole, Presta valve |
Hubs | Shimano TC500 alloy, CentreLock, thru axle |
Spokes | 14 g stainless steel, black |
Tyres | Size: XS , S - Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 27.5x2.60" Size: M , L , XL - Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.60" |
Handlebar | Size: XS , S - Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width Size: M , L , XL - Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width |
Stem | Size: XS , S - Bontrager Comp, 31.8 mm, 7-degree, 35 mm length Size: M , L - Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length Size: XL - Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length |
Grips | Trek Line Comp, nylon lock-on |
Seatpost | Size: XS , S - TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length Size: M , L , XL - TranzX JD-YSP18, 150 mm travel, internal routing, 31.6 mm, 470 mm length |
Saddle | Bontrager Verse P3, steel rails |
Headset | Semi-integrated, sealed cartridge bearing, alloy cups, 1-1/8" top, 1.5" bottom |
Extras | |
