Year | Generation 5 |
Frame | Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle |
Fork | Size: S - RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 46 mm offset, Boost110, 15 mm Maxle Stealth, 100 mm travel Size: M , L , XL - RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel |
Rear Shock | N/A |
Motor | Bosch Performance Line CX, 20 mph (25 km/h in Europe) |
Control System | Bosch Purion 200 |
Battery | Bosch PowerTube 800 Wh, smart system |
Display | |
Shifters | Shimano Deore M6100, 12-speed |
Rear Mech | Shimano XT M8100, long cage |
Front Mech | |
Bottom Bracket | |
Chainset | |
Cassette | Shimano Deore M6100, 10-51, 12-speed |
Chain | Shimano Deore M6100, 12-speed |
Brakes | Shimano 4-piston hydraulic disc, MT4100 lever, MT420 calliper |
Pedals | VP-536 nylon platform |
Wheelset | Rims: Bontrager Line TLR 30, Tubeless-Ready, 28-hole, Presta valve Hub F: Shimano TC500 alloy, CentreLock, 110x15 mm thru axle Hub R: Shimano TC500 alloy, CentreLock, 148x12 mm thru axle |
Tyres | Size: S - TBC 27.5" Size: M , L , XL - TBC 29" |
Handlebar | Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width |
Stem | Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length |
Grips | Bontrager XR Endurance Comp, lock-on |
Seatpost | Size: S - Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length Size: M , L , XL - Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length |
Saddle | Bontrager Commuter Comp |
Headset | FSA IS-2, 1-1/8" top, 1.5" bottom |
Extras | Charger - Bosch standard 4A, 230V, smart system |
